Sunflower Seed Dehulling and Separating Equipment TFKH-1500

Sunflower Seed Dehulling and Separating Equipment TFKH-1500

  • Functions and Features

This equipment can complete the cleaning, dehulling, shells-removing and seed-kernel separating of sunflower seeds at one time, and it’s the optimum choice for sunflower kernel processing industry in the world today. It features high dehulling rate, high percentage of whole kernels, high automation degree, easy operation and maintenance, etc.

  • Component

①input hopper
②spiral elevator
③multi-functional cleaner
④bucket elevator
⑤main part of the equipment(dehullers, air separator and seed-kernel separator)
⑥pneumatic system of back-flowing materials
⑦seed-kernel re-separator1
⑧seed-kernel re-separator2
⑨kernels bin ⑩electrical control cabinet

  • Technical Parameters
Power Input Capacity % of Whole Kernels (broken kernel is lessthan 1/2 of the whole one) % of Inshell in Kernels Overall Dimension (L*W*H)
Vertical Model 17.46kW (380v) 0.7-1.0mt/h 90% min. 5%max.  11.6mx3.3mx5.5m
Horizontal Model 17.7kW (380v)  0.7-1.0mt/h 90% min.  5% max.  5% max.
New Model 20.24kW (380v) 0.8-1.25mt/h 90% min.  5% max. 13.1mx2.92mx5.4m
